Solar Panel Wiring: Series vs Parallel Explained

You will probably never touch the wiring inside your own solar array — that is the qualified installer's job, and rightly so (see our DIY solar installation guide for exactly why the DC and AC connections are not a self-install task). But the choice your installer makes between wiring your panels in series, in parallel, or a mix of both, quietly shapes how your system behaves when a chimney shadow crosses the roof at 4pm, and it is worth understanding before you look at a design plan.

Series wiring: voltages add up

Wire panels in series and their voltages add together while the current stays the same. Connect three panels each producing 40V at 10A in series, and the string delivers 120V at 10A. Most crystalline panels have an open-circuit voltage around 35–45V, and most UK domestic string inverters need an input voltage window somewhere in the low hundreds of volts to operate efficiently, so a typical residential string runs 8–14 panels in series depending on the inverter and panel spec. Series strings are the default for most UK roofs because they are simple to wire, use less cabling, and keep resistive losses low — higher voltage at the same power means lower current, and lower current means thinner cable can carry it without excess heat loss.

Parallel wiring: currents add up

Wire panels in parallel and it's current that adds, while voltage stays at a single panel's level. Three of the same 40V/10A panels wired in parallel deliver 40V at 30A. Parallel wiring is far less common for whole-roof grid-tied arrays because that higher current needs heavier cable to avoid losses, but it shows up in small systems — portable and off-grid setups, or wiring multiple short strings together at a combiner box before a single inverter input. Our off-grid solar panels guide covers where parallel wiring turns up in practice on smaller battery-charging systems.

Series-parallel: the configuration most roofs actually use

Most multi-string residential arrays are wired as series-parallel — several short series strings, each wired in parallel with the others, feeding one or more inverter inputs. This gets the best of both: each string reaches a workable inverter voltage, while wiring multiple strings in parallel lets a bigger array split across roof faces or around obstructions without one giant string. It is also why a two-storey roof with panels on the front and back pitch is normally wired as two separate strings rather than one long one — each pitch gets different sun through the day, and mixing them into a single series string would drag the better-lit pitch down to the worse one's output.

Why shading hits a series string harder

Because current in a series string is set by its weakest link, one shaded panel can throttle the whole string. Solar cells connected in series in a typical PV string mean that when even one cell is significantly shaded, its reduced current output limits the current the entire string can carry — a chimney shadow on one panel can cut output from every panel behind it in that string, not just the shaded one. This is where bypass diodes come in: standard 60- or 72-cell panels are built with around three bypass diodes internally, each covering roughly a third of the panel's cells, so a shaded section can be routed around rather than throttling the whole panel. The trade-off is that the bypassed section's output is lost entirely while it's shaded, and a failed bypass diode leaves that section vulnerable to overheating (a “hot spot”) the next time it is shaded. This is one of the reasons roof shading assessment is a core part of a proper design — and, for panels with a stronger built-in tolerance to partial shading, why half-cut cell technology has become the near-default spec on new UK installs: splitting each cell in two halves wired in parallel limits how much of the panel a single shadow can knock out. DC power optimisers go a step further, managing each panel's output independently so one shaded panel in a string no longer drags down the others at all.

What this means when you're comparing a quote

You don't need to design the string layout yourself — that's the installer's job, checked against the inverter's MPPT voltage window and your specific roof geometry. But two practical things are worth asking about if your roof has any shading at all (a chimney, a neighbouring tree, a dormer window): whether the design splits your array into separate strings per roof face, and whether optimisers or a shade-tolerant panel spec are being used on any part of the roof that gets partial shade through the day. A design that ignores shading and runs one long series string across a mixed-light roof will under-perform its stated output — not because the panels are faulty, but because the wiring choice didn't account for the site.
