Cables & Accessories
Prysmian Solar DC Cable 6mm² (10m)
EN50618/H1Z2Z2-K rated 6mm² twin-core DC solar cable. UV-stabilised, rated to 1.8kV DC.
Reference spec — included for completeness, not separately rated
£28 per 10m
Specifications
- Length m
- 10
- Standard
- EN50618
- Conductor mm2
- 6
- Voltage rating (V)
- 1800
What I noticed
This is the correct cable for runs between solar panels and the inverter. Use H1Z2Z2-K or EN50618-rated cable — not standard flex, not twin-and-earth, not extension leads. The UV stabilisation matters for cable runs on the roof surface. Use 6mm² for any DC home-run over 5m to keep voltage drop below 2%.
How much to order
Measure the longest panel-to-panel run, add the roof-to-inverter run (including the route through the building), and double it (positive and negative). Add 20% for routing and dressing. A 10-panel, 2-storey install typically needs 20–30m total.
Sources — verified 4 June 2026
- Prysmian, “TECSUN (PV) H1Z2Z2-K 1X6 — Solar cable H1Z2Z2 K” — datasheet.prysmiangroup.com
