Midnite Solar DC Circuit Breaker 20A (pair)
DC-rated circuit breakers for string overcurrent protection. Pair of 20A, DC-rated to 600V.
Reference spec — included for completeness, not separately rated
£24 (pair)
Specifications
- Amps
- 20
- DC rated
- Yes
- Quantity
- 2
- Voltage v
- 600
What I noticed
DC circuit breakers are not the same as AC MCBs — never use AC breakers on DC circuits. You need one per string on the DC side of the inverter. For a single-string system (up to about 5kWp on a 20A breaker), one pair covers you. Check your inverter datasheet for the maximum overcurrent protection device rating for each MPPT input.
Sources — verified 4 June 2026
- MidNite Solar, “MNEPV / QY-Series DC Circuit Breakers Data Sheet” — midnitesolar.com
