Mounting & Racking
IronRidge XR100 Rail Kit (10-panel)
Heavy-duty aluminium rail system for 10 panels. Designed for high wind loads — suited for exposed sites.
Reference spec — included for completeness, not separately rated
~£245
Specifications
- Type
- on-roof
- Panels
- 10
- Material
- aluminium
- Spec sheet url
- https://files.ironridge.com/pitched-roof-mounting/resources/cutsheets/IronRidge_Cut_Sheet_XR100_Rail_US.pdf
- Wind load rating
- 3.2
What I noticed
IronRidge XR100 is heavier-duty than K2 and better suited to exposed coastal or highland sites. The XR100 rail profile is exceptionally stiff, reducing flex in high-wind conditions. More common in North American installs but increasingly available through UK distributors.
Installation notes
Compatible with most standard hook/foot systems. Pair with L-foot roof attachments appropriate for your tile type (flat, interlocking, slate). Order tile-specific hooks separately.
Sources — verified 4 June 2026
- IronRidge, “XR100 Rail (US) — Cut Sheet (v1.10)” — files.ironridge.com
- IronRidge, “XR Rail Family” — ironridge.com
